Information / general / Test Submission Platform Issues & Successes?

Between 11/30/2025 23:59 and 01/01/2026 00:00

Dunno how time keeps disappearing.

04:23

I'm just in the process of updating https://test-platform.wafer.space and also looking at deploying the "real" https://platform.wafer.space

Welcome to wafer.space …

Platform for wafer.space low cost silicon manufacturing.

04:29

The platform should be able to run 3 checks in parallel

"Permission denied"...

Image attachment

Noritsuna Imamura

"Permission denied"...

Poke me again in about 30m

1

Mine is stuck between "Check queued" and "Checking..." going back and forth.

09:24

Image attachment

09:24

Image attachment

09:24

cc @Tholin

I'm in the same situation.

Image attachment

Image attachment

Deploying a new version right now which should hopefully fix that.

@Tim 'mithro' Ansell do we need to resubmit?

It might start automatically.

10:42

It currently takes ~20m to do a deployment. I need to figure out why it takes so long but that is someone a future problem.

2

1

1

Well, that didn't work - trying again now.

1

Do you need help with this?

Running into differences between my local workstation and the remote vm.

11:54

Also regretting the decision to not make manufacturing checks work like download with seperate download attempts. One of the things to fix after we get past this bit.

IMHO it makes sense just to fire on VMs on demand for this (I think that's with ChipFoundry is doing?)

11:58

For TT sumbission we use fly.io

I am firing up docker containers on demand

Their advantage is that they can launch a vm in ~100 ms

11:59

(using firecracker, so it's actually some hybrid between VM and container)

The problem is mostly the django/celery code for managing the vm lifecycle stuff.

With fly they manage the lifecycle for you (but their compute is probably x10 more expensive compare with hetzner)

Things will be down for a little bit.

Should be back now.

Dispatched!

12:25

Image attachment

Dispatched means it's been sent to celery to run the docker command.....

Well, that is new......

12:41

@Leo Moser (mole99) - Something seems to have gone weird with nix in the docker container...

yeah

12:48

Image attachment

12:48

The error is:

       >        error: unable to download 'https://www.python.org/ftp/python/3.12.10/Python-3.12.10.tar.xz': Could not resolve hostname (6) Could not resolve host: www.python.org

12:49

looks like an intermittent DNS error to me?

The docker container doesn't have network access.

12:50

And nix should be running with --offline too...

The logs don't show the actual nix command, so unfortunately I can't help further

https://github.com/wafer-space/gf180mcu-precheck/actions/runs/19823322624/job/56790515702?pr=17

build: add precheck --help validation step to Dockerfile · wafer-s...

Precheck for wafer.space MPW runs using the gf180mcu PDK - build: add precheck --help validation step to Dockerfile · wafer-space/gf180mcu-precheck@bf512cd

12:58

docker run --rm --network=none -e COLUMNS=200 -e TERM=xterm-256color -v
    /home/django/platform.wafer.space/wafer_space/media/projects/562a942d-68e0-4370-8573-9cc36ffafd79/wafer-space.gf180mcu-project-template.r19704603402-a4686
    122452.0p5x0p5_gds.chip_top.gds:/input/design.gds:ro -w /workspace --memory 64g ghcr.io/wafer-space/gf180mcu-precheck:latest python3 precheck.py --input
    /input/design.gds --top "chip_top" --slot 0p5x0p5

I guess I have to re-submit the file to retry?

I can make it retry in a moment

When an error occurs, this screen appears and the processing logs disappear. How can I check the error logs?

Image attachment

Noritsuna Imamura

When an error occurs, this screen appears and the processing logs disappear. How can I check the error logs?

I just fixed the issue with the logs getting overwritten, its in the process of deploying.

1

Noritsuna Imamura

When an error occurs, this screen appears and the processing logs disappear. How can I check the error logs?

The real issue in your case is that the job which cleans up orphan docker containers cleaned up your docker container.

@Tim 'mithro' Ansell is the /home/django/platform… a correct path? since we submit to test-platform… (edited)

Yeah - the test-platform is suppose to just be the production deployment with a different name.

Tim 'mithro' Ansell

Yeah - the test-platform is suppose to just be the production deployment with a different name.

That's what I get if I try to run docker command on my Ubuntu machine (edited)

Image attachment

Did you change the bit after the -v to match where your GDS file is?

Tim 'mithro' Ansell

@Leo Moser (mole99) - Something seems to have gone weird with nix in the docker container...

Is this still an issue?

@Leo Moser (mole99) - no it seems to go away after I deleted the container and repulled

1

Noritsuna Imamura

When an error occurs, this screen appears and the processing logs disappear. How can I check the error logs?

Check seems to be running for your design now.

1

Tim 'mithro' Ansell

Did you change the bit after the -v to match where your GDS file is?

ah, turns out, I need to provide the full path from the ~/ not just local path (I was trying to run docker from the folder with gds files). Works now! (edited)

16:27

works: docker run --rm --network=none -v ~/z80-open-silicon-tapeout/z80_quarter.gds:/input/design.gds:ro ... doesn't: docker run --rm --network=none -v z80_quarter.gds:/input/design.gds:ro ... (edited)

Looks like it might finally be running

Image attachment

partyblob

2

It is GREEN!

Image attachment

17:33

️ ship it!

It's GREEN!

Image attachment

2

Looks like a bunch of the prechecks where able to be churned through last night...

urish

Do you need help with this?

The permission issues are because I went a little overboard with the privilege separation. The website can't write any files, only the download workers can. Only the docker workers can start/stop docker containers, etc.

00:32

And of course when running everything locally it all just runs as your user.

00:34

I do regret not putting the webapp and workers in their own docker containers, so then a deploy is just a few docker commands, rather than waiting for ansible to run a whole bunch of SSH commands which seem to each be taking 1.5 minutes rather than the 1 second they should.

We can finally join the it's green party too!

05:06

Image attachment

Tim 'mithro' Ansell

I do regret not putting the webapp and workers in their own docker containers, so then a deploy is just a few docker commands, rather than waiting for ansible to run a whole bunch of SSH commands which seem to each be taking 1.5 minutes rather than the 1 second they should.

1.5 minute to establish the connection or to push the container?

05:08

PDK_ROOT = /workspace/gf180mcu
PDK = gf180mcuD
Top cell: tt_gf_wrapper
Die ID: FFFFFFFF

I guess the DIE ID is not yet finalized?

urish

1.5 minute to establish the connection or to push the container?

1.5m to run a command on the server using SSH (like cat /etc/hostname)

06:10

Seems like some type of weird interaction between SSH jump hosts, ansible gather facts and other things I don't quite understand yet.

Long shot, but could be a DNS issue?

06:12

I've seen cases when failed DNS lookups really slow down systems

Shall we also submit on platform? or test-platform is enough?

test-platform should be enough

1

urish

PDK_ROOT = /workspace/gf180mcu
PDK = gf180mcuD
Top cell: tt_gf_wrapper
Die ID: FFFFFFFF

I guess the DIE ID is not yet finalized?

The die ID needs to be passed to the precheck by the online platform (#72). After this has been implemented, the precheck needs to run again. (@Tim 'mithro' Ansell)

Tim 'mithro' Ansell

The permission issues are because I went a little overboard with the privilege separation. The website can't write any files, only the download workers can. Only the docker workers can start/stop docker containers, etc.

https://platform.wafer.space failed to download the file because of:

Download Error:

Download failed: [Errno 13] Permission denied: '/home/django/platform.wafer.space/wafer_space/media/projects/91a731b3-d0a9-4cc3-bb72-dbc57afca703'

Is this because of the above?

Leo Moser (mole99)

https://platform.wafer.space failed to download the file because of:

Download Error:

Download failed: [Errno 13] Permission denied: '/home/django/platform.wafer.space/wafer_space/media/projects/91a731b3-d0a9-4cc3-bb72-dbc57afca703'

Is this because of the above?

Seems like that is fixed now, but yes.

Tim 'mithro' Ansell

Seems like that is fixed now, but yes.

Yes, precheck is running now

I could probably up the number of concurrent prechecks on the platform server. 4 isn't giving test-platform any trouble and it is slower than the primary machine.

1

Our GDS was all green in the production platform too.

Image attachment

2
